Excel Template: Road Cross Section Design & Chainage Drawing Tool for Civil Engineering Projects

Automate and simplify road cross-section design with this Excel tool. Ideal for civil engineers working on highway or infrastructure projects, featuring chainage-wise elevation profiles, OGL/FRL calculations, and detailed section drawings.

🔍 Key Features:

• Pre-built template for cross-section design between chainage points (e.g., 494+440 to 505+540)

• Auto-calculation of OGL (Original Ground Level) and FRL (Finished Road Level)

• Graphical chainage data visualization with annotations

• Tabular input for elevation data and horizontal distances

• Supports large-scale road projects (e.g., NH-234 or similar)

• Designed and used by experts with 28+ years in civil infrastructure (Sanjay Kumar Singh)

📊 Product Details:

• Format: Microsoft Excel (.xlsx)

• Usability: No macros needed; works in Excel 2010 and above

• Customization: Chainage ranges, number of sections, and elevations editable

• Included Sections: From KM 464.480 to KM 606.540 (as per real-world highway planning)

• Utility: Ideal for DPRs, engineering submissions, and project presentations

📦 Package Contents:

• 1 Excel Template File (.xlsx)

• Sample data from NH-234 project (for reference)

• Instruction tab with usage guide

🧽 Care Instructions:

• Use only in Microsoft Excel (desktop version)

• Do not delete formulas unless customizing with care

• Save a backup before editing
